tf1000-200hv-sl vacuum tube furnace
Model: TF1000-200HV-SL
Category: 3d-printing-heat-treatment-furnace, lab-furnace, tube-furnace, vacuum-heat-treatment-furnace
Applications:
This equipment can vacuum process the following materials: 3D printing titanium alloy materials, root canal files, vascular stents, bone plates, and vacuum brazing, etc.
Equipment Features:
- High yield.
- High vacuum degree, no oxidation on the surface.
- Simple operation and high production efficiency.
- Good stability and convenient operation and maintenance.
| Basic parameters | Control center | 10 inches LCD touch screen |
| Rated voltage | AC 380V,50/60Hz | |
| Total equipment power | 13Kw | |
| Heating system | Constant temperature zone | 200mm |
| Maximum temperature | 1000℃ | |
| Operating temperature | ≤900℃ | |
| Heating rate | ≤30℃/min（fastest） | |
| Temperature sensor | Thermocouple OMEGA N type imported from USA. | |
| Heating element | Infrared tube | |
| Temperature control instrument | Xiamen Yudian AI series instrument, fuzzy PID control and self-tuning adjustment function | |
| 15-stage programmable control, temperature control accuracy ±1℃ | ||
| Vacuum system | Ultimate vacuum | 6.67*10-4Pa（Empty furnace, cold state） |
| Vacuum unit power | 1Kw | |
| Compound molecular pump | JTFB-600 | |
| Rotary Vane Mechanical Pump | VRD-4 | |
| Furnace tube and size | Quartz tube，200*900mm | |
| High vacuum pipe plug | Stainless Steel Insulation Pipe Plug | |
| Chiller | CW-5200 | |
| Security | Over-temperature alarm, broken couple prompt, over-current protection, leakage protection | |
| When the furnace body needs to be opened to observe the material or to accelerate the cooling, the power supply will be automatically cut off to ensure the safety of the users. | ||
| Molecular pump fault alarm and stop running | ||
| Warranty | The warranty period is 12 months, except for wearing parts (such as furnace tubes, sealing rings, etc.) | |
